BELT 13X865
OPTIBELT

Belt 13x865

Profile: AVX13

Width (mm): 13

Internal length (mm): 802

Primitive development Ld (mm): 847

External length (mm): 865

Height (mm): 10

Suitable for rear tensioner: No

Toothed: Yes

Number of sections: 1

Tension rope material: Polyester

Maximum working speed (m/s): 55

Min. working temperature (°C): -40

Max. operating temperature (°C): 120

Minimum pulley diameter (mm): 80

Definite constant (matched): No

Oil resistant: Yes

Detailed description: - Step length = External length - 18 mm - Internal length = External length - 63 mm

Product details: - V-belts according to DIN 7753 part 3 - High efficiency - Low maintenance - Smooth running and long service life - Excellent load behavior - Temperature range from -40 °C to +120 °C

TECHNICAL DATA

Profile: AVX13
Length: 13 mm
Internal length (mm): 802 mm
Early development Ld (mm): 847 mm
External length (mm): 865 mm
Height: 10 mm
Suitable for rear tensioner: No
Toothed: Yes
Number of sections: 1
Tension rope material: Polyester
Maximum working speed (m/s): 55
Minimum working temperature: -40 °C
Maximum working temperature: 120 °C
Minimum pulley diameter (mm): 80 mm
Definite constant (abbinata): No
Oil resistant: Yes

CODE: AVX13865M2

EAN 4014486357820

COMPATIBLE SPARE PART, NOT ORIGINAL
